V700 Vertical Windlass 12V 6&7mm
V700 Vertical Windlass 12V 6&7mm
V700 Vertical Windlass 12V 6&7mm V700 Vertical Windlass 12V 6&7mm
Lewmar

V700 Vertical Windlass 12V 6&7mm

Catalogue Code: 840996
£599.95 Available in selected stores
Save £96.19 RRP £696.14
See Product Description Add to Wish List
  • Order will be dispatched within 5 working days
  • Ask a question
Optional Extras Tick to add optional extras to your basket
Hand Held Windlass Control Switch
Hand Held Windlass Control Switch £117.95 Save £52.76 RRP £170.71

View all 3 optional extras

  • Description
  • Availability
  • Delivery & Returns
  • Questions & Answers
  • Reviews
Description
Lewmar V700 Vertical Windlass 12V 6&7mm

FREE PAIR OF STAINLESS STEEL FOOTSWITCHES WITH THIS WINDLASS WORTH £153.90

While stocks last. Free foot switches are p/nos 841245 & 841246

With 100% 316 stainless steel housing and a sleek flush-mount design that hides the motor down below, the V700 is one of the most attractive and durable windlasses on the market. It works at the push of a button and has two built-in features that make it unique – motor protection and anchor lock.

Lewmar Part No: 6670011108-312

Features:

  • Fits calibrated chains: 6mm DIN766, 1/4" G4 or BBB, 7mm DIN766
  • Minimal parts for enhanced reliability
  • 100% 316 stainless steel deck unit
  • IP67 Rated (Waterproof to 1 meter)
  • Fall Safe anchor lock
  • Fast line speed
  • Manual recovery option
  • Impact-resistant motor cover
  • 5-year warranty
  • For boats up to 10.5m (35 ft)
  • Magnet & sensor kit for chain counter available on request



Specifications:

  • Motor supply voltage 12V
  • Motor power 320W
  • Typical max pull 320kg/700lb
  • Max line speed 25m/min/82 ft/min
  • Working load 79kg/175lb
  • Nominal current draw 45A
  • Circuit breaker 35A
  • Cable sizing: 0-15mtr/0-50ft: 10mm2/8AWG
  • Switch Wiring: 1.5mm2/16AWG
  • Current rating for switch wire: 5A



In the Box:

  • V700 Windlass
  • Circuit breaker
  • Rocker switch
  • Contactor box
  • Documentation



Download Product Manual here.

Please Note: This Product Manual covers a number of V700 models, please make sure that you select the correct information for your Windlass
