GPSMAP 922xs Plus Multifunction Display
- Delivery & Returns
Advanced navigation. Ultimate integration. This compact 9” GPSMAP® 922xs Plus touchscreen combo features enhanced map drawing and seamlessly integrates into your Garmin marine system for full control of your connected helm. It supports 1 kW CHIRP traditional sonar, ClearVü scanning sonar and Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar. NMEA 2000® and NMEA 0183 networking connect you to autopilots, digital switching, weather, media, VHF, AIS and other sensors.
- Bright, sunlight-readable 9” intuitive touchscreen combo with enhanced map drawing
- Built-in 1 kW CHIRP traditional and ClearVü scanning sonar (transducers sold separately)
- Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar
- J1939 engine connectivity for easy integration with engines, such as Yamaha, and our exclusive OneHelm™ feature for connecting to third-party devices, such as EmpirBus™ digital switching
- Easily build your marine system — from sonar and autopilots to cameras and multimedia — using NMEA 2000® and NMEA 0183 network connectivity and the Garmin Marine Network
- Supports optional BlueChart® g3 Vision® premium charts
- Built-in Garmin SailAssist™ features, including laylines, race features, set and drift, wind data and more
- Add free all-in-one ActiveCaptain® app to manage your marine experience from nearly anywhere
- Integrated ANT® technology support for use with quatix® marine watches, gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls
OPTIONAL BLUECHART® G3 VISION® CHARTS
These optional charts offer the best of Garmin and Navionics® data, Auto Guidance technology and other premium navigation features.
TRADITIONAL AND SCANNING SONARS
Get built-in support for 1 kW CHIRP traditional sonar for superior target separation and ClearVü scanning sonar to see up to 1,000’ (300 m) below your boat at 260 kHz (transducer sold separately).
GARMIN SAILASSIST™ SAILING FEATURES
View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed and more.
GARMIN MARINE NETWORK
If you have multiple Garmin devices on your boat, you can share information – such as charts, user data, radar and IP cameras – among them.
NMEA 2000® AND NMEA 0183 NETWORKS
Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm, Garmin Quickdraw™ Community data and more.
INTEGRATED ANT® TECHNOLOGY
Connect with some of your favourite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.
Now you can connect your chartplotter to different kinds of engines, including Yamaha engines.
This exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus™ digital switching, on one screen.
PANOPTIX™ SONAR SUPPORT
Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.
- Dimensions: 25.6 x 16.2 x 5.2 cm
- Display size, WxH: 19.6 x 11.4 cm (9" diag)
- Display resolution, WxH: 1024 x 600 pixels
- Weight: 1.2 kg
- Antenna: Internal or external over NMEA 2000
- NMEA 2000® & NMEA 0183 compatible
- Video input ports:1 BNC
- Typical current draw at 12 Vdc: 1.2 A
- Mounting options: Bail, flat or flush
- Garmin Marine Network™ ports:1
- 2 microSD™ cards
- Waypoints 5,000: Routes 100
- Track log 50,000 points; 50 saved tracks
- Sonar frequencies supported: (dependent on transducer)
- Traditional: 50/77/83/200 kHz
- CHIRP (low, medium, high)
- ClearVü (260/455/800 kHz)
- Transmit power:1 kW traditional; 1 kW single channel CHIRP
- Maximum Depth: 5,000 ft (1524 m) at 1kW (depth capacity is dependent on water bottom type and other water conditions)
- Transducer connection pins: 8 pin
