Garmin GPSMAP 722xs Plus Multifunction Display

Advanced navigation. Ultimate integration. This compact 9” GPSMAP® 722xs Plus touchscreen combo features enhanced map drawing and seamlessly integrates into your Garmin marine system for full control of your connected helm. It supports 1 kW CHIRP traditional sonar, ClearVü scanning sonar and Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar. NMEA 2000® and NMEA 0183 networking connect you to autopilots, digital switching, weather, media, VHF, AIS and other sensors.

  • Bright, sunlight-readable 7” intuitive touchscreen combo with enhanced map drawing
  • Built-in 1 kW CHIRP traditional and ClearVü scanning sonar (transducers sold separately)
  • Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar
  • J1939 engine connectivity for easy integration with engines, such as Yamaha, and our exclusive OneHelm™ feature for connecting to third-party devices, such as EmpirBus™ digital switching
  • Easily build your marine system — from sonar and autopilots to cameras and multimedia — using NMEA 2000® and NMEA 0183 network connectivity and the Garmin Marine Network
  • Supports optional BlueChart® g3 Vision® premium charts
  • Built-in Garmin SailAssist™ features, including laylines, race features, set and drift, wind data and more
  • Add free all-in-one ActiveCaptain® app to manage your marine experience from nearly anywhere
  • Integrated ANT® technology support for use with quatix® marine watches, gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls

OPTIONAL BLUECHART® G3 VISION® CHARTS
These optional charts offer the best of Garmin and Navionics® data, Auto Guidance technology and other premium navigation features.

TRADITIONAL AND SCANNING SONARS
Get built-in support for 1 kW CHIRP traditional sonar for superior target separation and ClearVü scanning sonar to see up to 1,000’ (300 m) below your boat at 260 kHz (transducer sold separately).

GARMIN SAILASSIST™ SAILING FEATURES
View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed and more.

GARMIN MARINE NETWORK
If you have multiple Garmin devices on your boat, you can share information – such as charts, user data, radar and IP cameras – among them.

NMEA 2000® AND NMEA 0183 NETWORKS
Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.

ACTIVECAPTAIN® APP
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm, Garmin Quickdraw™ Community data and more.

INTEGRATED ANT® TECHNOLOGY
Connect with some of your favourite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.

J1939 CONNECTIVITY
Now you can connect your chartplotter to different kinds of engines, including Yamaha engines.

ONEHELM™ FEATURE
This exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus™ digital switching, on one screen.

PANOPTIX™ SONAR SUPPORT
Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.

Specifications

  • Dimensions: 22.4 x 14.3 x 5.4 cm
  • Display size, WxH: 15.4 x 8.6 cm (7" diag)
  • Display resolution, WxH: 800 x 480 pixels
  • Weight: 1.1 kg
  • Antenna: Internal or external over NMEA 2000
  • NMEA 2000® & NMEA 0183 compatible
  • Video input ports:1 BNC
  • Typical current draw at 12 Vdc: 1.1 A
  • Mounting options: Bail, flat or flush
  • Garmin Marine Network™ ports:1
  • 2 microSD™ cards
  • Waypoints 5,000: Routes 100
  • Track log 50,000 points; 50 saved tracks
  • Sonar frequencies supported: (dependent on transducer)
    • Traditional: 50/77/83/200 kHz
    • CHIRP (low, medium, high)
    • ClearVü (260/455/800 kHz)
  • Transmit power:1 kW traditional; 1 kW single channel CHIRP
  • Maximum Depth: 5,000 ft (1524 m) at 1kW (depth capacity is dependent on water bottom type and other water conditions)
  • Transducer connection pins: 8 pin

In The Box

  • GPSMAP 722xs Plus Chartplotter
  • Power cable
  • Bail mount with knobs
  • Flush mount kit with gasket
  • Protective cover
  • Trim piece snap covers
  • Documentation
