X2 Low Profile 8mm Vertical Windlass - Aluminium 12V 1000W
- Delivery & Returns
- Questions & Answers
Lofrans windlasses have an excellent reputation for quality, reliability and performance. Straightforward to install and requiring little maintenance, the lightweight aluminium gypsy base unit sits on the deck with the horizontal motor and gearbox assembly below deck. A pre-fitted sensor in the base and a magnet in the gypsy allows easy connection to an optional chain counter system. Made from marine grade anodised aluminium, the rope/chain gypsy will handle both 8mm chain and 14mm 3-strand warp. In an emergency it can also be used manually.
- 6 position motor gearbox mounting orientation
- Watertight st. steel ball bearings in the base
- Rope and chain combination gypsy
- Manual chain release
- Manual override available for chromed bronze models only
- Chain counter pre-setting as standard
- Motor IP-rating 66 (12/24V)
- Anodised marine aluminium gearbox
- Quick release moor gearbox coupling for smilified maintenance
- Suitable for boats up to 14m
- Gypsy Size: 8mm (5/16”), DIN 766, ISO 4565
- Motor: 12V / 1000W
- Current Draw: 117A
- Max Pull: 1000kg
- Lift Working Load: 150kg
- Max Lift Load: 500kg
- Haulage speed: 25 to 45 m/min
- Weight: 19kg
- Size Overall (On deck): L232 x W162, Height above deck: 153mm, Depth below deck: 150mm
In the box
- X2 Aluminium deck unit
- Motor gearbox assembly
- Control box
- Manual operation handle
- Base Gasket
- User Manual
